PRAMAC Off Grid LX 45/80

The PRAMAC Off Grid LX 45/80 is a versatile Battery Energy Storage System (BESS) designed to deliver reliable AC power through various sources, including external grid supply, diesel generators, or solar PV. It efficiently manages energy to ensure cost-effectiveness and minimal environmental impact. The system includes a deep-cycle lithium-ion LFP battery module with a nominal capacity of 76.8 kWh and offers a usable energy of 66 kWh at 90% depth of discharge. This unit features advanced control via a touch screen display, GSM remote monitoring, automatic full system bypass, and an auto remote call to a generator if needed. The LX 45/80 is capable of providing a continuous output power of 45 kVA and can handle a peak output of 75 kW for short durations. It operates at a voltage of 400/230 V, and a frequency of 50 Hz across three phases. Built for both efficiency and durability, the system includes a lithium-ion LFP battery rated at 48 volts, designed for a lifespan of up to 6000 cycles at 90% depth of discharge. With remote communication capabilities, users can monitor and maintain the system from any global location, ensuring ongoing performance and reliability.
